D.O.T. AIR BRAKE - HOSE / ENDS

AIR BRAKE - HOSE/ENDS - D.O.T.

D.O.T. AIR BRAKE - HOSE/ENDS

•Typical Application Air Brake hose connections. Meets SAE & DOT specifications (FMVCS 10 GAL)

•Pressure Determined by maximum working pressure for hose size. Up to 125 psi

•Material CA360 Brass. Temperature: -400 F to + 1200 F ( -40°C to +48°C )

•Advantages Can be used for nearly any brake line. Easy to assemble with a good selection of hose end configurations. Brass material offers excellent resistance against corrosion.

• Tolerance +/- .02 on all dimensions. Dimension data can change without notice. Please call us when dimensions are critical.

•Assembly Instructions 1- Slide nut and sleeve onto hose. Make sure bevel edge of sleeve faces out toward fitting. 2- Push hose into fitting until it bottoms. 3- Screw nut until contact is made with body hex. NOTE: When reassembling fitting, body and nut should be inspected. Only reuse if in proper condition. Sleeves should never be reused.
