BRASS HOSE BARB FITTINGS

BRASS HOSE BARB FITTINGS - HOSE I.D. - NPTF - BRASS FITTINGS

MATERIAL:  CA360 Brass for Barstock fittings. CA377 Brass for Forged fittings.

TEMPERATURE AND PRESSURE RANGE: From -40F t 160F at 150 PSI maximum.

BRASS HOSE BARB FITTING INTERNAL VIEW

HOSE SIZES 3/16, 1/4, 5/16 INCH      A =1/4 INCH

HOSE SIZE 3/8, 1/2, 5/8, 3/4 INCH      A = 1/8 INCH

ACTUAL PROFILE OF HOSE BARBS

ACTUAL HOSE BARB PROFILE

1/8 INCH EQUALS 0.165 INCHES ACTUAL PROFILE

3/16 INCH EQUALS 0.227 INCHES ACTUAL PROFILE

1/4 INCH EQUALS 0.29 INCHES ACTUAL PROFILE

5/16 INCH EQUALS 0.354 INCHES ACTUAL PROFILE

3/8 INCH EQUALS 0.415 INCHES ACTUAL PROFILE

1/2 INCH EQUALS 0.53 INCHES ACTUAL PROFILE

5/8 INCH EQUALS 0.645 INCHES ACTUAL PROFILE

3/4 INCH EQUALS 0.79 INCHES ACTUAL PROFILE

1 INCH EQUALS 1.02 INCHES ACTUAL PROFILE

Please Note: These hose barb fittings are intended for use with hose clamp, similar type clamp or a crimped ferrule.

Assembly Instructions
1- Cut hose cleanly and squarely to length. 2- Slide clamp on hose. 3- Lubricate hose. Push hose on fitting until hose bottoms against stop ring or hex. 4- Position hose clamp as shown below and secure with a screwdriver or wrench. Maintain “A” dimension noted below for proper clamp positioning.
