BRASS GARDEN HOSE FITTINGS
Temperature and Working Pressure Ranges From +35F to +100F at 75 PSI maximum or the recommended working pressure of the garden hose. (Not to exceed 150 PSI) Note: All female connector ends should have a rubber washer inserted prior to usage. Male garden hose threads are all 3/4” with an outside diameter of 1.0625 and 11-1/2” threads per inch.
FGH = Female Garden Hose threads
MGH = Male Garden Hose threads
GARDEN HOSE FITTING DIAGRAM
MALE GARDEN HOSE PROFILE
